4-Piece Base Davit Kit | 30070KIT
EN 795:2012 Type B, EN 1496
The 30070KIT is a complete Pro-3 Series system built around a portable base, enabling confined space access without requiring permanent anchorage. With upper and lower mast sections and a winch system for personnel lifting, it is suitable for rotating between multiple job sites or short-term rescue installations.
- Includes portable base for flexible deployment
- Modular Pro-3 mast system
- Suitable for personnel lifting, access, and retrieval
- Easy to assemble and transport between sites
Product Details |
|
|---|---|
| Product Code | 30070KIT |
| Conformance | EN795 TYPE B | EN1496 |
| Life Span | 10 years |
| Service | Various |
| Weight | 28kg (Base Only) |
| Includes | 30070 | 30105 | 30109 | 60005 | 60209 |
Supporting Documents
Spec Sheet: 4-Piece Base (30070)
0.33 MB
Download
Kit Contents
Pro-3 Upper Davit Arm (Large) | 30105
EN 795:2012 Type B
The 30105 Pro-3 Upper Davit Arm is ideal for operations that demand greater vertical clearance. Offering a 71cm reach and height adjustment between 147cm and 170cm, it enables safe and efficient access over tanks, pits, or vaults. Designed for use with Pro-3 Series lower masts and compatible with front or rear-mounted fall protection equipment.
- 71cm outreach for rescue and entry positioning
- Extended height adjustment: 147–170cm
- Supports front/rear-mounted devices (winches, SRLs)
- Built to endure industrial use
Pro-3 Lower Davit Mast (Large) | 30109
EN 795:2012 Type B
The 30109 Pro-3 Lower Mast extends your rescue system’s vertical reach to 132cm. Built for compatibility with Tuff Built’s upper davit arms, it offers added clearance when working over deeper or obstructed entry points. Durable and easy to set up, it’s ideal for a wide range of industrial and utility applications.
- 132cm mast height for deeper access requirements
- Seamless integration with Pro-3 upper arms
- Built for harsh industrial environments
- Lightweight and corrosion-resistant
TUFF Personnel Winch, 30m | 60005
EN 795, EN 1496
The TUFF Personnel Winch (60005) is engineered to provide dependable lifting and lowering capabilities for personnel in various working-at-height scenarios. With a 30-metre galvanised steel rope and an 11:1 mechanical advantage, this winch ensures controlled and effortless operation. Its robust design accommodates a maximum load of 280kg when used with a double-reeved system, making it suitable for both personnel and material handling within prescribed limits. The integrated rapid stop brake offers a maximum stopping distance of 610mm, enhancing safety during operations. Compatible with Abtech Safety’s T3 and RT3 tripods via the T05TW2 bracket, the 60005 winch is ideal for confined space entry, rescue missions, and industrial maintenance tasks.
- 30m galvanised steel rope for extended reach
- 11:1 mechanical advantage for efficient operation
- Maximum load capacity of 280kg with double-reeved system
- Rapid stop brake with a maximum stopping distance of 610mm
- Compatible with T3 and RT3 tripods using T05TW2 bracket
Davit Bracket | 60209
EN 795 Type B
The 60209 Davit Bracket facilitates the secure attachment of winches and fall arrest devices equipped with fittings specific to Tuff Built Pro-3 Series davits (models 30104, 30105, 30108, 30109). Constructed from steel and aluminium, this bracket ensures reliable performance in demanding environments.
- Compatible with a range of winches and fall arrest devices
- Fits Tuff Built Pro-3 Series davits
- Durable steel and aluminium construction
Add Ons
Winch Carry Bag, Wood Base | WINCHBAG
Winch devices are heavy-duty. Their carry bag should be too. This carry bag with solid base offers optimum protection.
- Solid Base
- Zip Closure
- Internal Velcro Straps
